Faital PRO 18HP1022

SKU: 18HP1022

1.322,09 lei
1.111,00 lei fără TVA

1 în stoc

0 People watching this product now!

Livrare rapidă

Produs garantat

Consultanță

Calitate garantată

Descriere
Faital Pro 18HP1022 18″ Speaker Driver 1000 W 8 Ohm



Nominal Specifications



  • Nominal Diameter – 460 mm (18 in)
  • Overall Diameter – 460 mm (18.11 in)
  • Bolt Circle Diameter – 440 mm (17.32 in)
  • Baffle Cutout Diameter – 422 mm (16.61 in)
  • Depth – 202 mm (7.95 in)
  • Flange and Gasket Thickness – 14 mm (0.55 in)
  • Net Weight – 6.6 Kg (14.6 lb)
  • Shipping Box(Single Carton Box) – 503 x 500 x 258 mm (19.8 x 19.7 x 10.2 in)
  • Shipping Weight – 7.8 Kg (17.2 lb)

Technical Parameters



  • Nominal Impedance – 8 Ohm
  • Minimum Impedance – 6.5 Ohm
  • AES Power Handling (1) – 1000 W
  • Maximum Power Handling (2) – 2000 W
  • Sensitivity (1W/1m) – 98 dB
  • Frequency Range – 35-1600 Hz
  • Voice Coil Diameter – 100 mm (4 in)
  • Winding Material – Cu
  • Former Material – Glass Fiber
  • Winding Depth – 23 mm (0.91 in)
  • Magnetic Gap Depth – 12 mm (0.47 in)
  • Flux Density – 1.3 T
  • Magnet – Neodymium Slug
  • Basket Material – Aluminum
  • Demodulation – No
  • Cone Surround (3) – Triple Roll
  • NET Air Volume filled by Loudspeaker – 5.8 l (0.205 ft^3)
  • Spider Profile – 2x non-adjacent symmetrical constant height waves



Thiele and small parameters



  • Fs – 35 Hz
  • Re – 5.4 Ohm
  • Qes – 0.31
  • Qms – 14.4
  • Qts – 0.3
  • Vas – 179 l (6.32 ft^3)
  • Sd – 1124 cm^2 (174.22 in^2)
  • Xmax (4) – 9.50 mm
  • Xdamage (5) – 17.5 mm
  • Mms – 207.0 g
  • Bl – 28 N/A
  • Le – 1.75 mH
  • Mmd – 185.7 g
  • Cms – 0.10 mm/N
  • Rms – 3.67 Kg/s
  • Eta Zero – 2.43 %
  • EBP – 113 Hz
Informații suplimentare
Greutate 6,60000000 kg
